Basic info

Clapboard	without Clapboard	Filter Number	1
Medium Material	Nonwoven Fabric	Efficiency	G4
Filtration Grade	Pre Filter	Type	Panel Filter
Trademark	HZJ FILTER	Transport Package	Carton Box
Specification	24x24x1	Origin	China
HS Code	8421999000

Product Description

Part No.	HZJ-P-1002	Efficiency	MERV 6
Filtration grade	Primary	Type	Panel pleated
Size	24x24x1	Colour
Frame	Cardboard	Filter media	Nonwoven
Max. Temp.	180 °F	Production capacity	10,000pcs per day
Transport Package	Standard carton	Certificates
Place of origin	Jiangsu, China	Warranty	1 year
Air flow	3400m3/h	Resistance	20Pa
Advantages	Cheap, widely used	Disadvantages	Low efficiency
Application	Hospital, Pharmaceutical plants, Chip plants, Stockbreeding, Glass screen factory, Photovoltaic plants, PCB factory, Exhibition center, Painting booth, Semi-conductor plant, Hotels, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Restaurant, Home Use, Construction works , Energy & Mining,

Pre filter pleated filters are low cost, easy to install, one-use pleated V-Form filter. Often used as a pre-filter for spray booths , furnaces and air-conditioning (HVAC) systems.

Application: HVAC pre-filters, industrial, spray booth, Hospital, Pharmaceutical plants, Chip plants, Stockbreeding, Glass screen factory, Photovoltaic plants, PCB factory, Exhibition center, Painting booth, Semi-conductor plant, Hotels, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Restaurant, Home Use, Construction works , Energy & Mining,

Filter Frame: cardboard frame
Filter Media: Nonwoven cloth
Filter efficiency: Merv 6
Initial Presssure drop : 20Pa
Maximum temperature : 180°F

All standard sizes are available:

Metric (mm)	Imperial (")	Metric (mm)	Imperial (")
287 x 592 x 20	12 x 24 x1	287 x 592 x 46	12 x 24 x 2
592 x 592 x 20	24 x 24 x1	592 x 592 x 46	24 x 24 x 2
287 x 490 x 20	12 x 20 x1	287 x 490 x 46	12 x 20 x 2
490 x 490 x 20	20 x 20 x1	490 x 490 x 46	20 x 20 x2
287 x 287 x 20	12 x 12 x 1	287 x 592 x 96	12 x 24 x 4
287 x 390 x 20	12 x 16 x 1	592 x 592 x 96	24 x 24 x 4
390 x 390 x 20	16 x 16 x 1	390 x 390 x 46	16 x 16 x 2
390 x 490 x 20	16 x 20 x 1	390 x 490 x 46	16 x 20 x 2
*Any other sizes are customized
